YFMA520/650 Fully Automatic Glueless and Thermal Film Laminating Machine

Feature

YFMA520/650 is small and automatic laminating machine according to market it has compact structure and function is perfect. We choose international electricity brand and system for him. It has PLC system, touch-screen plate, oil heating built in steel roller: Feeder, laminating system, sheeting and stacker are automatic. It can laminate glueless film and BOPP thermal film. It is best useful for greating cards, documents, book covers, package etc.


Configuration

1.Feeder is vacuum pump system without oil system.

2.Feeder will stop when monitoring lack paper or broken paper by sensors.

3.Improted servo motor makes sure the precision of laps among paper.

4.Human-computer interface: color touch screen plate, easy automatic operation for inputing paper sizes and laps. From it you can after check the satuation of running.

5.Eletrcity magnetic neating system has quick neating and saves power.

6.Hydraulic pressure: automatic adjustment pressure.

7.Gas expanded shaft: precise and convenint.

8.Tension system: adjustment of film tension and speed.

9.Film width cuter: it can cut film width according to your paper width.

10.Film hole knife: it makes holes on film edge for sheeting easily.

11.Anti-curve device; finishing laminating paper will not curve when it crosses the anti-curve device.

12.Automatic gas cutting system.

13.Vibrating stacker and corrugated paper system.

Technical Specification

Model

YFMA520

YFMA650

Max. Laminating size

520*600mm

650*750mm

Min. Laminating size

220*280mm

220*280mm

Speed

0-35m/min

0-35m/min

Paper thickness

100-500g/m2

100-500g/m2

Power

18kw/380v

18kw/380v

Dimension

4000*1200*1600mm

4000*1400*1600mm

Weight

1800kg

2000kg
